AR0M2073BA, AR207V-P,ADSL2+ ANNEX A/M WAN,8FastEthernet LAN(POE),4FXS+1FXO,1USB,PoE
Huawei Router AR0M2073BA, AR207V-P,
AR207V-P , AR0M2073BA Overview
Huawei AR G3 AR200 Series - AR207V-P fixed interface access voice router with POE capacity AR0M2073BA provides routing and switching functionality for small business or branch offices.
Huawei AR207V-PV-P integrates 1 ADSL2+ ANNEX A/M WAN, 8 Fast Ethernet 10/100 LAN(POE),4FXS+1FXO,1USB and 1 PoE Power Adapter. The comprehensive security features with and fault detection ensure safe, secure, scalable communications.
AR200 series router voice features provide industry-leading voice quality and user experience and can easily be integrated within new or existing data networks. FXO&FXS ports connect with PBX system serves as the SIP access gateway for a branch office, transforming phone signals into VoIP signals.
Huawei AR G3 AR169FGVW-L router offers most efficient solution for the small business, remote office or branch office.
AR207V-P , AR0M2073BA Specification
| Product Code | Huawei Router - AR207V-P |
| Memory | 512 MB |
| Flash | 512 MB |
| Service interfaces (standard configuration) | WAN interfaces: 1 ADSL-A/M interface LAN interfaces: 8 10/100M auto-sensing Ethernet electrical interfaces Voice interface: 4 FXS interfaces and 1 FXO interface |
| Extended slots | Not supported |
| Interface number | LAN interfaces: FE0-FE7 |
| Power module type | External power adapter |
| Weight | 2.8 kg (6.17 lb) |
| Dimensions (W x D x H) | 300.0 mm x 216.4 mm x 44.0 mm |
Order Information
NE20E-M2F NECMHSTB0200 AR01WEG4SB
S5720-50X-EI-46S-DC CE6850-48T4Q-EI CE6851-48S6Q-HI
CR5P03BASD73 S5700S-52P-LI-AC S2700-26TP-PWR-EI
