HUAWEI AirEngine5760-10 Wi-Fi6 Supports 2 * 2 MIMO Dual Band Transmission

Name: HUAWEI AirEngine576010 WiFi6 Supports 2 2 MIMO Dual Band Transmission
Brand: AirEngine5760-10
Price: 1 USD

Wholesale HUAWEI AirEngine5760-10 Wi-Fi6 Supports 2 * 2 MIMO Dual Band Transmission from china suppliers

Brand Name : AirEngine5760-10

Model Number : AirEngine5760-10 Wi-Fi6

Certification : CE

Place of Origin : China

Products Status : Stock

Type : Indoor Ap

Form Factor : Internal

Screen Size : 3.5

Dimensions (H x W x D) : 47 x 200 x 200 mm

Antenna Type : Built-in smart antennas

Contact Now

HUAWEI AirEngine5760-10 Wi-Fi6 Supports 2 * 2 MIMO Dual Band Transmission

Product Description

AirEngine5760-10

AirEngine Wi-Fi 6 (802.11ax) wall plate Access Point, 2 x 2 MIMO, 2.4 GHz and 5 GHz bands, up to 1.774 Gbit/s

AirEngine 5760-10 is a Wi-Fi 6 (802.11ax) Access Point (AP) that supports 2 x 2 Multiple-Input Multiple-Output (MIMO), delivering services on both the 2.4 GHz and 5 GHz bands, achieving a rate of up to 1.774 Gbit/s. With built-in smart antennas that enable signals to follow Stations (STAs), providing better coverage, the AP is ideal for Small and Medium Enterprises (SMEs), cafés, and entertainment venues.

Quick Specs

Table 1 shows the Quick Specs.

Model Number	AirEngine5760-10
Power Input	DC: 12 V ± 10% PoE: In compliance with IEEE 802.3at
Maximum Power Consumption	15.8 W (excluding output power consumption of the USB interface and IoT) Note: The actual maximum power consumption depends on local laws and regulations.
Maximum Number of Users	≤ 512 Note: The actual number of users varies according to the environment.
Maximum Transmit Power	2.4G: 25 dBm (combined power) 5G: 25 dBm (combined power) Note: The actual transmit power depends on local laws and regulations.
MIMO: Spatial Streams	2.4G: 2 x 2:2 5G: 2 x 2:2
Radio Protocols	802.11a/b/g/n/ac/ac Wave 2/11ax
Maximum Rate	1.774 Gbit/s

HUAWEI AirEngine5760-10 Wi-Fi6 Supports 2 * 2 MIMO Dual Band Transmission

Product Tags:

Dual Band Transmission Fiber Optic Module

AirEngine5760 Optical Module Transceiver

Huawei Wifi 6 Enterprise Access Point

HUAWEI AirEngine5760-10 Wi-Fi6 Supports 2 * 2 MIMO Dual Band Transmission Images
